Heap Abstraction

Author

Bor-Yuh Evan Chang

Published

Thursday, November 20, 2025

$\newcommand{\TirName}[1]{\text{#1}} \newcommand{\inferlab}[3]{ \let\and\qquad \begin{array}{l} \TirName{#1} \\ \displaystyle \frac{#2}{#3} \end{array} } \newcommand{\inferright}[3]{ \let\and\qquad \displaystyle \frac{#2}{#3}\TirName{#1} } \newcommand{\inferrule}[3][]{\inferlab{#1}{#2}{#3}} \newcommand{\infer}[3][]{\inferrule[#1]{#2}{#3}} $

What questions do you have? What questions does your neighbor have?

Announcements

Project presentation (Mon Dec 8 1:30-4 p.m.)
Project paper (Fri Dec 12 AoE)
Extra support
- Extra office hours (before and after class today 8:30am-1:00pm)
- Happy to review your “proposals” over break

See advice on final projects.

Questions?

Exercise: Chaotic Iteration

\[ \begin{array}{rrll} \hat{\Sigma}( \ell_0 ) & = & \hat{\rho}_0 \\ \hat{\Sigma}( \ell_i ) & = & \bigsqcup_{ \ell_j \mathrel{\mathord{-}\mkern-4mu[c]\mkern-4mu\mathord{\rightarrow}} \ell_i \in g} \{ \hat{\rho}' \mid \hat{\Sigma}(\ell_j) \vdash c \Downarrow\hat{\rho}' \} & \text{for $i \neq 0$} \end{array} \]

The chaotic iteration algorithm computes the least fixed-point invariant $\hat{\Sigma}_\omega$ by iterating at each location $\ell_i$ until convergence.

r = 1;
while
  (n > 0) {
    r = r * x;
    n = n - 1;
  }

Fill in the following table where each $\hat{\Sigma}_i$ is the $i$th iterate using the sign abstract domain. Cell $\hat{\Sigma}_0(\ell_0)$ is $\hat{\rho}_0$, which consider to be $\top$.

	$\hat{\Sigma}_0$	$\hat{\Sigma}_1$	$\hat{\Sigma}_2$	$\hat{\Sigma}_3$	$\hat{\Sigma}_4$	$\hat{\Sigma}_5$	$\hat{\Sigma}_6$	$\hat{\Sigma}_7$	$\hat{\Sigma}_8$	$\hat{\Sigma}_9$	$\hat{\Sigma}_{10}$	$\hat{\Sigma}_\omega$
$\ell_0$	$\top$
$\ell_1$	$\bot$
$\ell_2$	$\bot$
$\ell_3$	$\bot$
$\ell_4$	$\bot$
$\ell_5$	$\bot$
$\ell_6$	$\bot$

Chaotic Iteration

Let us use the convention that empty cells mean that the abstract store at location is unchanged from the previous iterate and $\cdot$ means we have detected a fixed point at that location.

	$\hat{\Sigma}_0$	$\hat{\Sigma}_1$	$\hat{\Sigma}_2$	$\hat{\Sigma}_3$	$\hat{\Sigma}_4$	$\hat{\Sigma}_5$	$\hat{\Sigma}_6$	$\hat{\Sigma}_7$	$\hat{\Sigma}_8$	$\hat{\Sigma}_9$	$\hat{\Sigma}_{10}$	$\hat{\Sigma}_{\omega}$
$\ell_0$	$\top$
$\ell_1$	$\bot$	$\texttt{r} \mapsto\mathsf{+}$
$\ell_2$	$\bot$		$\texttt{r} \mapsto\mathsf{+}$				$\top$				$\cdot$
$\ell_3$	$\bot$			$\texttt{r} \mapsto\mathsf{+}$				$\top$
$\ell_4$	$\bot$				$\top$				$\cdot$
$\ell_5$	$\bot$					$\top$				$\cdot$
$\ell_6$	$\bot$											$\top$

Exercise: Reflection: Chaotic Iteration

What is the worst-case complexity of chaotic iteration?

For efficiency, chaotic iteration is typically done by following the reverse post-order of the weak topological order of the strongly-connected components. What does this mean?

How could we generalize chaotic interation to infinite height domains?

Reflection: Chaotic Iteration

What is the worst-case complexity of chaotic iteration?

For a lattice with height $h$ and procedure with $n$ program locations, chaotic iteration is $O(h \cdot n)$ in the worst case.

For efficiency, chaotic iteration is typically done by following the reverse post-order of the weak topological order of the strongly-connected components. What does this mean?

Intuitively, find the fixed points of inner loops before outer loops.

How could we generalize chaotic interation to infinite height domains?

Intuitively, apply widening $\mathbin{\nabla}$ at some program location within each loop.

Exercise: Widening

i = 0;
while
  (i < n) {
    i = i + 1;
  }

Fill in the following table where each $\hat{\Sigma}_i$ is the $i$th iterate using the interval abstract domain with widening at the loop head $\ell_2$. Cell $\hat{\Sigma}_0(\ell_0)$ is $\hat{\rho}_0$, which consider to be $\top$.

	$\hat{\Sigma}_0$	$\hat{\Sigma}_1$	$\hat{\Sigma}_2$	$\hat{\Sigma}_3$	$\hat{\Sigma}_4$	$\hat{\Sigma}_5$	$\hat{\Sigma}_6$	$\hat{\Sigma}_7$	$\hat{\Sigma}_8$	$\hat{\Sigma}_9$	$\hat{\Sigma}_{10}$	$\hat{\Sigma}_\omega$
$\ell_0$	$\top$
$\ell_1$	$\bot$
$\ell_2$	$\bot$
$\ell_3$	$\bot$
$\ell_4$	$\bot$
$\ell_5$	$\bot$

Widening

	$\hat{\Sigma}_0$	$\hat{\Sigma}_1$	$\hat{\Sigma}_2$	$\hat{\Sigma}_3$	$\hat{\Sigma}_4$	$\hat{\Sigma}_5$	$\hat{\Sigma}_6$	$\hat{\Sigma}_7$	$\hat{\Sigma}_8$	$\hat{\Sigma}_\omega$
$\ell_0$	$\top$
$\ell_1$	$\bot$	$\texttt{i} \mapsto[0, 0]$
$\ell_2$	$\bot$		$\texttt{i} \mapsto[0, 0]$			$\texttt{i} \mapsto[0, \infty)$			$\cdot$
$\ell_3$	$\bot$			$\texttt{i} \mapsto[0, 0]$			$\texttt{i} \mapsto[0, \infty)$
$\ell_4$	$\bot$				$\texttt{i} \mapsto[1, 1]$			$\texttt{i} \mapsto[1, \infty)$
$\ell_5$	$\bot$									$\texttt{i} \mapsto[0, \infty)$

Summary: An Abstract Interpretation Template

Syntax

expressions $\quad e$

statements $\quad s$

Concrete Semantic Domains

values $\quad v$

states $\quad \sigma$

Concrete Semantics

$\fbox{$\sigma \vdash e \Downarrow v$}$

$\fbox{$\sigma \vdash s \Downarrow\sigma'$}$

Forward-Reachable Collecting Semantics

$\begin{array}{rrrl} \text{value properties} & V& \mathrel{::=}& \circ\mid V,v \end{array}$

$\begin{array}{rrrl} \text{state properties} & \Sigma& \mathrel{::=}& \circ\mid\Sigma,\sigma \end{array}$

$\fbox{$\lbrace\!\lbrack\!\lbrack e \rbrack\!\rbrack\!\rbrace = \lambda \Sigma.V$}$

$\fbox{$\lbrace\!\lbrack\!\lbrack s \rbrack\!\rbrack\!\rbrace = \lambda \Sigma.\Sigma'$}$

$\lbrace\!\lbrack\!\lbrack e \rbrack\!\rbrack\!\rbrace\,\Sigma = \{ v \mid \text{$\sigma \vdash e \Downarrow v$ and $\sigma\in \Sigma$} \}$

$\lbrace\!\lbrack\!\lbrack s \rbrack\!\rbrack\!\rbrace\,\Sigma = \{ \sigma' \mid \text{$\sigma \vdash s \Downarrow\sigma'$ and $\sigma\in \Sigma$} \}$

Abstract Domains

$\begin{array}{rrrl} \text{abstract values} & \hat{v} \end{array}$

$\begin{array}{rrrl} \text{abstract states} & \hat{\sigma} \end{array}$

$\fbox{$\gamma(\hat{v}) = V$}$

$\fbox{$\gamma(\hat{\sigma}) = \Sigma$}$

$\fbox{$\lbrack\!\lbrack e \rbrack\!\rbrack^\sharp = \lambda \hat{\sigma}.\hat{v}$}$

$\fbox{$\lbrack\!\lbrack s \rbrack\!\rbrack^\sharp = \lambda \hat{\sigma}.\hat{\sigma}'$}$

$\gamma( \lbrack\!\lbrack e \rbrack\!\rbrack^\sharp\,\hat{\sigma} ) \supseteq \lbrace\!\lbrack\!\lbrack e \rbrack\!\rbrack\!\rbrace\, \gamma(\hat{\sigma}) \quad $for all $\hat{\sigma}$

$\gamma( \lbrack\!\lbrack s \rbrack\!\rbrack^\sharp\,\hat{\sigma} ) \supseteq \lbrace\!\lbrack\!\lbrack s \rbrack\!\rbrack\!\rbrace\, \gamma(\hat{\sigma}) \quad $for all $\hat{\sigma}$

Dynamic Memory Allocation

JavaScripty Syntax

$\begin{array}{rrrl} \text{expressions} & e& \mathrel{::=}& \cdots \mid e\texttt{.}f \end{array}$

$\begin{array}{rrrl} \text{statements} & s& \mathrel{::=}& \cdots \mid x \mathrel{\texttt{=}}\texttt{\{\}} \mid e_1\texttt{.}f \mathrel{\texttt{=}}e_2 \end{array}$

\[ \text{fields} \quad f \]

Concrete Semantic Domains

$\begin{array}{rrrl} \text{values} & v& \mathrel{::=}& \cdots \mid a \\ \text{addresses} & a \end{array}$

$\begin{array}{rrrl} \text{states} & \sigma& \mathrel{::=}& \rho \\ \text{stores} & \rho& \mathrel{::=}& \circ \mid\rho,l \mapsto v \\ \text{l-values} & l& \mathrel{::=}& x\mid a\mathord{.}f \end{array}$

Exercise: Abstract Domains for Dynamic Memory Allocation

What are concrete semantic components are unbounded? Suggest some abstraction ideas.

Points-To Analysis

Allocation Sites

$\begin{array}{rrrl} \text{statements} & s& \mathrel{::=}& \cdots \mid\ell\colon s \end{array}$

locations $\quad \ell$

Statement $\ell\colon s$ is a location-labeled statement. For example, $\ell\colon x \mathrel{\texttt{=}}\texttt{\{\}}$ is an object allocation statement $x \mathrel{\texttt{=}}\texttt{\{\}}$ at location $\ell$.

Pointer Language: Syntax

$\begin{array}{rrrl} \text{statements} & s& \mathrel{::=}& x \mathrel{\texttt{=}}y \mid\ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} \mid x \mathrel{\texttt{=}}y\texttt{.}f \mid x\texttt{.}f \mathrel{\texttt{=}}y \mid s_1\;s_2 \end{array}$

variables $\quad x , y$

$\begin{array}{rrrl} \text{values} & v& \mathrel{::=}& a^{\ell} \\ \text{addresses} & a \\ \text{locations} & \ell \end{array}$

The composite statement $s_1\;s_2$ executes an arbitrary interleaving of $s_1$ and $s_2$ an arbitrary number of times (i.e., the program is viewed as a bag of the atomic statements).

Variants of this language $s$ are called Andersen-style statements. Note that there is no expression language, and statements are in an A-normal form.

Exercise: Pointer Language: Concrete Semantics

\[ \fbox{$\sigma \vdash s \Downarrow\sigma'$} \]

Define the judgment form $\sigma \vdash s \Downarrow\sigma'$ to say, “In state $\sigma$, pointer statement $s$ can evaluate to $\sigma'$.” Note that evaluation for pointer statements is non-deterministic.

Pointer Language: Concrete Semantics

\[ \fbox{$\sigma \vdash s \Downarrow\sigma'$} \]

$\infer{ }{ \sigma \vdash x \mathrel{\texttt{=}}y \Downarrow \sigma(x \leftarrow \sigma(y) ) }$

$\infer{ a\notin \operatorname{dom}(\sigma) }{ \sigma \vdash \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} \Downarrow \sigma(x \leftarrow a^{\ell} ) }$

$\infer{ a^{\ell} = \sigma(y) }{ \sigma \vdash x \mathrel{\texttt{=}}y\texttt{.}f \Downarrow \sigma(x \leftarrow \sigma( a^{\ell}\mathord{.}f ) ) }$

$\infer{ a^{\ell} = \sigma(x) }{ \sigma \vdash x\texttt{.}f \mathrel{\texttt{=}}y \Downarrow \sigma( a^{\ell}\mathord{.}f \leftarrow \sigma(y) ) }$

$\infer{ \sigma \vdash s_1 \Downarrow\sigma' \and \sigma' \vdash s_1\;s_2 \Downarrow\sigma'' }{ \sigma \vdash s_1\;s_2 \Downarrow\sigma'' }$

$\infer{ \sigma \vdash s_2 \Downarrow\sigma' \and \sigma' \vdash s_1\;s_2 \Downarrow\sigma'' }{ \sigma \vdash s_1\;s_2 \Downarrow\sigma'' }$

$\infer{ }{ \sigma \vdash s_1\;s_2 \Downarrow\sigma }$

Exercise: Allocation-Site Address Abstraction

Define an abstract domain $\hat{v}$ and its concretization $\gamma(\hat{v})$ for the allocation-site abstraction.

Allocation-Site Address Abstraction: Domain

$\begin{array}{rrrl} \text{value properties} & V& \mathrel{::=}& A \\ \text{address properties} & A& \mathrel{::=}& \circ\mid A,a^{\ell} \end{array}$

$\begin{array}{rrrl} \text{abstract values} & \hat{v}& \mathrel{::=}& \circ\mid\hat{v},\hat{a} \\ \text{abstract addresses} & \hat{a}& \mathrel{::=}& \ell \end{array}$

Abstract addresses $\hat{a}$ are allocation sites, and abstract values $\hat{v}$ are sets of abstract addresses. Sets of abstract addresses are also called points-to sets.

Allocation-Site Address Abstraction: Concretization

$\fbox{$\gamma(\hat{v}) = V$}$

$\fbox{$\gamma(\hat{a}) = A$}$

$\begin{array}{rrl} \gamma(\circ) & \mathrel{:=}& \emptyset \\ \gamma( \hat{v},\hat{a} ) & \mathrel{:=}& \gamma(\hat{v}) \cup \gamma(\hat{a}) \end{array}$

$\begin{array}{rrl} \gamma(\ell) & \mathrel{:=}& \{ a^{\ell} \mid \text{true} \} \end{array}$

Exercise: Store Abstraction

Define an abstract domain $\hat{\rho}$ and its concretization $\gamma(\hat{\rho})$ to lift the allocation-site abstraction to stores.

Field-Sensitive Store Abstraction

\[ \begin{array}{rrrl} \text{abstract states} & \hat{\sigma}& \mathrel{::=}& \hat{\rho} \\ \text{abstract stores} & \hat{\rho}& \mathrel{::=}& \circ \mid\hat{\rho},\hat{l} \mapsto\hat{v} \\ \text{abstract l-values} & \hat{l}& \mathrel{::=}& x\mid\hat{a}\mathord{.}f \end{array} \]

The field-sensitive store abstraction is a non-relational lifting of the allocation-site abstraction to stores.

Field-Sensitive Store Abstraction: Concretization

$\fbox{$\gamma(\hat{\rho}) = P$}$

$\begin{array}{rrl} \gamma(\circ) & \mathrel{:=}& \emptyset \\ \gamma( \hat{\rho},x \mapsto\hat{v} ) & \mathrel{:=}& \{ \rho,x \mapsto v \mid v\in \gamma(\hat{v}) \} \\ \gamma( \hat{\rho},\hat{a}\mathord{.}f \mapsto\hat{v} ) & \mathrel{:=}& \{ \rho,a^{\ell}\mathord{.}f \mapsto v \mid \text{$a^{\ell} \in \gamma(\hat{a})$ and $v\in \gamma(\hat{v})$} \} \end{array}$

Points-To Analysis as an Abstract Interpretation

Define points-to analysis as an abstract interpretation $\lbrack\!\lbrack s \rbrack\!\rbrack^\sharp = \lambda \hat{\sigma}.\hat{\sigma}'$ on pointer statements $s$.

Points-To Analysis as an Abstract Interpretation

\[ \fbox{$\lbrack\!\lbrack s \rbrack\!\rbrack^\sharp = \lambda \hat{\sigma}.\hat{\sigma}'$} \]

\[ \begin{array}{rrl} \lbrack\!\lbrack x \mathrel{\texttt{=}}y \rbrack\!\rbrack^\sharp\,\hat{\sigma} & \mathrel{:=}& \hat{\sigma}(x \leftarrow \hat{\sigma}(y) ) \\ \lbrack\!\lbrack \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} \rbrack\!\rbrack^\sharp\,\hat{\sigma} & \mathrel{:=}& \hat{\sigma}(x \leftarrow \ell) \\ \lbrack\!\lbrack x \mathrel{\texttt{=}}y\texttt{.}f \rbrack\!\rbrack^\sharp\,\hat{\sigma} & \mathrel{:=}& \hat{\sigma}(x \leftarrow \bigcup_{\hat{a}\in \hat{\sigma}(y)} \hat{\sigma}( \hat{a}\mathord{.}f ) ) \\ \lbrack\!\lbrack x\texttt{.}f \mathrel{\texttt{=}}y \rbrack\!\rbrack^\sharp\,\hat{\sigma} & \mathrel{:=}& \bigsqcup_{\hat{a}\in \hat{\sigma}(x)} \hat{\sigma}( \hat{a}\mathord{.}f \leftarrow \hat{\sigma}(y) ) \\ \lbrack\!\lbrack s_1\;s_2 \rbrack\!\rbrack^\sharp\,\hat{\sigma} & \mathrel{:=}& \operatorname{lfp}\,\lambda \hat{\sigma}'. \hat{\sigma}\mathbin{\sqcup}\lbrack\!\lbrack s_1 \rbrack\!\rbrack^\sharp\,\hat{\sigma}' \mathbin{\sqcup}\lbrack\!\lbrack s_2 \rbrack\!\rbrack^\sharp{\hat{\sigma}'} \end{array} \]

Points-To Analysis as Set Constraints

\[ \fbox{$\hat{\sigma}( \hat{l}) \supseteq \hat{v}$} \]

$\infer{ x \mathrel{\texttt{=}}y }{ \hat{\sigma}( x) \supseteq \hat{\sigma}(y) }$

$\infer{ \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} }{ \hat{\sigma}( x) \supseteq \{ \ell \} }$

$\infer{ x \mathrel{\texttt{=}}y\texttt{.}f \and \hat{a}\in \hat{\sigma}(y) }{ \hat{\sigma}( x) \supseteq \hat{\sigma}( \hat{a}\mathord{.}f ) }$

$\infer{ x\texttt{.}f \mathrel{\texttt{=}}y \and \hat{a}\in \hat{\sigma}(x) }{ \hat{\sigma}( \hat{a}\mathord{.}f ) \supseteq \hat{\sigma}( y) }$

The judgment form $s$ says, “Atomic statement $s$ is in the program (i.e., the bag of atomic statements).” The program is an implicit parameter of the judgment form.

The result of a points-to analysis is the least $\hat{\sigma}$ that satisfies $\hat{\sigma}( \hat{l}) \supseteq \hat{v}$ for a given program.

This subset-based formulation is called Andersen’s Analysis. Replacing subset $\supseteq$-constraints with equality $=$-constraints is called unification-based or Steensgaard’s Analysis.

Points-To Analysis as Set Constraints

\[ \fbox{$\operatorname{pt}( \hat{l}) \supseteq \hat{v}$} \]

$\infer{ x \mathrel{\texttt{=}}y }{ \operatorname{pt}( x) \supseteq \operatorname{pt}(y) }$

$\infer{ \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} }{ \operatorname{pt}( x) \supseteq \{ \ell \} }$

$\infer{ x \mathrel{\texttt{=}}y\texttt{.}f \and \hat{a}\in \hat{\sigma}(y) }{ \operatorname{pt}( x) \supseteq \operatorname{pt}( \hat{a}\mathord{.}f ) }$

$\infer{ x\texttt{.}f \mathrel{\texttt{=}}y \and \hat{a}\in \operatorname{pt}(x) }{ \operatorname{pt}( \hat{a}\mathord{.}f ) \supseteq \operatorname{pt}( y) }$

Field-Insensitive Store Abstraction

$\begin{array}{rrrl} \text{abstract states} & \hat{\sigma}& \mathrel{::=}& \hat{\rho} \\ \text{abstract stores} & \hat{\rho}& \mathrel{::=}& \circ \mid\hat{\rho},\hat{l} \mapsto\hat{v} \\ \text{abstract l-values} & \hat{l}& \mathrel{::=}& x\mid\hat{a} \end{array}$

$\infer{ x \mathrel{\texttt{=}}y }{ \hat{\sigma}( x) \supseteq \hat{\sigma}(y) }$

$\infer{ \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} }{ \hat{\sigma}( x) \supseteq \{ \ell \} }$

$\infer{ x \mathrel{\texttt{=}}y\texttt{.}f \and \hat{a}\in \hat{\sigma}(y) }{ \hat{\sigma}( x) \supseteq \hat{\sigma}( \hat{a}) }$

$\infer{ x\texttt{.}f \mathrel{\texttt{=}}y \and \hat{a}\in \hat{\sigma}(x) }{ \hat{\sigma}( \hat{a}) \supseteq \hat{\sigma}( y) }$

Field-Based Store Abstraction

$\infer{ x \mathrel{\texttt{=}}y }{ \hat{\sigma}( x) \supseteq \hat{\sigma}(y) }$

$\infer{ \ell\colon x \mathrel{\texttt{=}}\texttt{\{\}} }{ \hat{\sigma}( x) \supseteq \{ \ell \} }$

$\infer{ x \mathrel{\texttt{=}}y\texttt{.}f }{ \hat{\sigma}( x) \supseteq \hat{\sigma}( f) }$

$\infer{ x\texttt{.}f \mathrel{\texttt{=}}y }{ \hat{\sigma}( f) \supseteq \hat{\sigma}( y) }$
